OpenCanvas

Discover OpenCanvas: Find and read high-quality scientific articles, research papers, and compelling stories. Explore our library and expand your knowledge today.

Table of Contents

Project Structure

opencanvas/
├── client/                  # React frontend (Vite)
│ └── src/
│   ├── pages/           # Route-level page components
│   ├── components/      # Shared UI components
│   ├── contexts/        # React context providers (Auth, Theme, etc.)
│   └── services/        # API call helpers (dataService.js, etc.)
└── server/                  # Express backend
  └── src/
    ├── models/          # Mongoose schemas
    ├── routes/          # Express route handlers
    ├── middlewares/     # Auth, error handling, fingerprinting
    ├── services/        # Caching, image upload, notifications
    └── jobs/            # Cron job logic

Technology Stack

Frontend

  • React 18 with Vite
  • React Router v6
  • TailwindCSS
  • shadcn/ui component library
  • TanStack Query for server state
  • Axios for HTTP requests
  • Sonner for toast notifications

Backend

  • Node.js with Express
  • MongoDB with Mongoose
  • Passport.js (Google OAuth 2.0 strategy)
  • JSON Web Tokens for stateless authentication
  • node-cron for scheduled jobs
  • Helmet for HTTP security headers
  • Morgan for request logging

Architecture Overview

The backend is a stateless REST API. Authentication is handled entirely through JWTs - no server-side sessions are used. Passport is only involved in the Google OAuth redirect flow; once a token is issued it is verified on every subsequent request by the authenticateToken middleware.

Two middleware functions are composed on protected routes:

  1. authenticateToken - verifies the Bearer token and attaches req.userId.
  2. checkUserExists - fetches the full User document and attaches req.user. Only used on routes that need the user's role, profile data, or sub-documents (e.g. featuredItems, collections).

Engagement data (likes, saves, follows) is stored in dedicated collections (Interaction, Follow) and also reflected as denormalised counters on the parent documents (User.stats, Post.stats). The counters are updated atomically with $inc and exist purely for read performance.

Database Models

User

Stores account credentials, profile data, notification preferences, and cached statistics.

Field Type Notes
username String Unique, 4-16 chars, lowercase letters/numbers/underscores only
email String Unique, lowercase
provider String "google" or "opencanvas"
role String "user", "moderator", or "admin"
profilePicture String URL
designation String Max 40 chars
aboutMe String Max 300 chars
interestedIn [String] Max 8 topics
contactInformation [ContactInfo] Public links (title + URL), no _id
premiumUser Object Subscription status and dates
stats Object Denormalised counters: followers, following, posts, likesReceived
collections [ObjectId] References to Collection documents, max 50
featuredItems [FeatureItem] Pinned posts/collections shown on profile, max 8
lastFiveLogin [LoginInfo] Rolling log of last 5 logins (time, device, IP)
notifications Object Per-type boolean flags

Post

Stores the full content and metadata for a written post.

Field Type Notes
title String Required
content String Full post body (Markdown)
contentPreview String 700 chars sliced for preview
slug String URL-friendly title fragment
authorId ObjectId Reference to User
authorSnapshot Object Denormalised username, profilePicture, fullName
isPublic Boolean Controls visibility
isEdited Boolean Set to true after the first update
type String written, article, poem, story, or social
tags [String] Max 5
media [String] Uploaded image URLs
stats Object viewsCount, likesCount, dislikesCount, sharesCount, commentsCount, readsCount
anonymousEngagementScore Number Recalculated every 15 minutes by cron
engagementScore Number Personalised variant (reserved for future use)

Collection

A named, ordered list of posts created by a user.

Field Type Notes
title String Required
description String
isPrivate Boolean Default false
tags [String] Max 5
authorId ObjectId Reference to User
posts [ObjectId] References to Post documents, max 50
stats Object likesCount, dislikesCount, viewsCount

Follow

A directional edge in the social graph between two users.

Field Type Notes
followerId ObjectId The user who is following
followingId ObjectId The user being followed
since Date Creation timestamp (replaces createdAt)

A unique compound index on (followerId, followingId) prevents duplicate follows.

Interaction

Records a user's like, dislike, or save action on a Post, Collection, or Comment.

Field Type Notes
userId ObjectId
targetId ObjectId Post, Collection, or Comment ID
targetModel String "Post", "Collection", or "Comment"
type String "like", "dislike", or "save"

A unique compound index on (userId, targetId, type) prevents duplicate interactions.

Comment

Supports a single level of threading: top-level comments and direct replies.

Field Type Notes
content String Max 1000 chars
authorId ObjectId
postId ObjectId The post this comment belongs to
parentId ObjectId null for top-level; set to parent comment ID for replies
authorSnapshot Object username and profilePicture
stats Object likesCount, dislikesCount, repliesCount

API Reference

All responses follow the shape { success: boolean, data?, message?, error? }. The error field is only included in development.

Authentication

Method Path Auth Description
GET /auth/google None Initiates Google OAuth flow
GET /auth/google/callback None OAuth callback; redirects with JWT
GET /auth/user Required Returns current user's full document

Users

Method Path Auth Description
GET /u/:username Optional Public profile (checks follow status if token provided)
GET /u/users/byids?ids=... None Batch-fetch minimal user data
GET /u/top/writers None Top 5 writers by engagement (Cached)
PUT /update/user Required Update own profile

Posts

Method Path Auth Description
GET /p/:slug None Fetch single public post
GET /u/posts/byids?ids=... None Batch-fetch public post cards
GET /u/:userId/posts None Public posts by a specific author
GET /u/posts/mine Required Own posts including private
GET /saved/posts Required Saved posts for logged-in user
GET /get-new-post-id Required Reserve new post ObjectId for editor
GET /private/p/:slug Required View private post (author/mod)
GET /post/:postId/my-interactions Required Like/dislike/save state for a post
POST /post/like-dislike Required Toggle like/dislike
POST /post/save-unsave Required Toggle save state
POST /save/post/written Required Upsert written post
PUT /change-post-visibility-status Required Toggle public/private
PUT /change-post-featured-status Required Pin/unpin on profile
PATCH /update-post-views/:slug None Increment view counter (fingerprinted)
DELETE /post/delete Required Delete post

Post URL format: /p/<title-slug>-<24-char-objectid>. The ObjectId is always the last segment and is used for the database lookup. The slug is cosmetic.

Comments

Method Path Auth Description
GET /p/:postId/comments None Paginated top-level comments
GET /p/comments/:commentId None Single comment + direct replies
GET /get-comments/byids?ids=... None Batch-fetch comments
POST /new-comment Required Create top-level comment
POST /reply-to-comment Required Reply to existing comment
PUT /edit-comment Required Edit own comment
DELETE /delete-comment Required Delete comment

Collections

Method Path Auth Description
GET /collections None Browse public collections
GET /c/:collectionId None Public collection + posts
GET /u/:userId/collections Required User's collections metadata
GET /c/private/:collectionId Required Private collection (author/mod)
POST /create/collection Required Create new collection
POST /collection/:collectionId/vote Required Toggle like/dislike on collection
PUT /update-collection/:collectionId Required Update metadata
PUT /add-remove-post/:postId/collection/:collectionId Required Toggle post in/out of collection
DELETE /delete-collection/:collectionId Required Delete collection

Feed

Method Path Auth Description
GET /articles None Cursor-paginated public feed (Cached)
POST /articles/anonymous-user None Legacy engagement-ranked feed

Follow

Method Path Auth Description
POST /follow-unfollow/user Required Toggle follow on a user
GET /u/:userId/followers None Paginated followers list
GET /u/:userId/following Required Paginated following list

Search

Method Path Auth Description
GET /search?q=...&type=... None Global search for users and posts

Authentication Flow

  1. The client redirects the user to GET /auth/google.
  2. Google authenticates the user and redirects to GET /auth/google/callback.
  3. The server finds or creates a User document, signs a 7-day JWT, and redirects the client to FRONTEND_URL/auth/success?token=<jwt>.
  4. The frontend stores the token and sends it as Authorization: Bearer <token> on all subsequent requests.
  5. Protected routes validate the token via authenticateToken. Routes that need the full user document additionally call checkUserExists.

Access Control

Three roles exist: user, moderator, and admin.

  • Post/comment deletion: author, moderator, or admin.
  • Private post/collection viewing: author, moderator, or admin.
  • Collection/post management: author only (update, feature, visibility, add/remove posts).
  • Follow/save/like: any authenticated user.
  • Public profile, public posts, public collections, feed: no authentication required.

Engagement Scoring

The anonymousEngagementScore field on Post drives the ranked feed for logged-out users. A cron job runs every 15 minutes and recalculates the score for all posts using a weighted formula that combines views, likes, reads, and recency. The formula lives in server/src/jobs/updateEngagementScore.js.

Posts without a score are not shown in the ranked feed but do appear in the chronological /articles feed.

Environment Variables

All variables are read from a .env file in the server/ directory.

Variable Description
PORT Server port (default: 3000)
NODE_ENV "development" or "production"
SESSION_SECRET hard to guess string
JWT_SECRET hard to guess string
FRONTEND_URL Public URL of the frontend (used for CORS and post-auth redirects)
CURRENT_URL Public URL of the server (used to build the OAuth callback URL), use localhost:3000 in dev
CURRENT_URL_LOCAL used in dev, http://localhost:3000
MONGODB_URI MongoDB connection string
MONGODB_URI_PROD MongoDB connection string
IMGUR_API_URL https://api.imgur.com/3/upload
IMGUR_CLIENT_ID your imgur client id
GOOGLE_CLIENT_SECRET Google OAuth client secret
GOOGLE_CLIENT_SECRET Google OAuth client secret

All variables are read from a .env file in the client/ directory.

Variable Description
VITE_BACKEND_URL http://localhost:3000

Running Locally

Prerequisites: Node.js 18+, MongoDB running locally or a MongoDB Atlas URI.

# clone the repo
git clone git@github.com:Dream-World-Coder/opencanvas.git

# or
git clone https://github.com/Dream-World-Coder/opencanvas.git
# Install server dependencies
cd server
pnpm install

# Start the server
pnpm dev # single worker
pnpm devCluster # for cluster
# Install client dependencies
cd client
pnpm install

# Start the dev server
pnpm dev

The backend listens on http://localhost:3000 by default. The Vite dev server runs on http://localhost:5173 and is included in the CORS allow-list automatically when NODE_ENV is not "production".

Alternatively, use the provided shell scripts from the project root:

# for macOS only, uses homebrew
chmod +x start.sh stop.sh

./start.sh   # Start both client and server & mongodb
./stop.sh    # Stop all processes

And for clusters instead of a single thread:

# for macOS only, uses homebrew
chmod +x cluster-start.sh cluster-stop.sh

./cluster-start.sh
./cluster-stop.sh

Performance Benchmarks

To ensure the platform scales gracefully, the database was seeded with a massive dataset: 400,000 users, 100,000 posts, 500,000 interactions, 100,000 follows, and 320,000 comments.

The Optimizations

To handle this volume and maximize Requests Per Second (RPS), the following backend optimizations were implemented:

  • Denormalization: Embedded authorSnapshot directly into post documents.
  • Payload Reduction: Introduced contentPreview (first 700 characters) to avoid sending full article bodies in the feed, saving massive bandwidth.
  • Lean Queries: Replaced .populate() and utilized .lean() for faster read operations.
  • Aggregation & Pipelining: Grouped database calls and utilized pipelined requests.
  • Atomic Operations: Offloaded interaction tracking to a separate Interaction collection and used $inc for atomic stat updates on parent documents.
  • Caching: Implemented an in-memory TTL cache for high-traffic routes like the feed.
  • Database Indexing: Ensured proper indexing and replaced expensive .skip() operations with cursor-based pagination.

Autocannon Stress Tests (The /articles Feed)

These optimizations yielded incredible improvements on a single Node.js thread, which were then scaled further using Node Cluster mode.

Condition (10s Test) Pre-Optimization Post-Optimization (Single Thread) Post-Optimization (Cluster Mode)
Simple (100 conn) 1,993 RPS (Avg: 49ms) 6,138 RPS (Avg: 15ms) 15,913 RPS (Avg: 5ms)
Stressed (500 conn, 10 pipe) 2,504 RPS (Avg: 1609ms) 6,679 RPS (Avg: 353ms) 17,007 RPS (Avg: 209ms)

The optimized single thread handles 2.6x more traffic under stress, and cluster mode achieves nearly a 7x increase in RPS over the unoptimized baseline.

Artillery Real-World Load Simulation

A comprehensive Artillery load test was run simulating a real-world scenario (Warm up → Ramp up → Sudden Viral Spike) totaling 8,600 concurrent user requests.

The Single Thread performance metrics were exceptional:

  • Success Rate: 100% (0 request failures during peak viral spike).
  • Latency Consistency: The median response time was 1ms.
  • Percentiles: The p95 response time was an impressive 1ms, and the p99 was 2ms, proving that even the absolute slowest requests were resolved near-instantly despite the heavy cache-miss and DB stress conditions.
  • Max Latency: Only peaked at 18ms across the entire test cycle.

Support

Hi, I'm Subhajit, an IT undergrad at IIEST Shibpur. While exploring various research works, I noticed a recurring problem: countless early-stage college research papers never see the light of day. They either get stuck in the publishing pipeline or remain buried deep within individual university websites, making them incredibly difficult for enthusiasts to find.

My goal is to build a middle ground between ResearchGate and Reddit. By creating dedicated channels for specific colleges, this platform provides a centralized hub to easily publish, discover, and discuss early-stage scientific work.

If you find this project valuable and believe in making academic research more accessible, consider supporting my work! (The platform currently relies on free hosting tiers (Vercel, Render, MongoDB Atlas). Your contribution will help upgrade to standard plans, ensuring consistent uptime and a reliable experience for everyone.)

Support my work: https://ko-fi.com/myopencanvas

Version

This is a prototype just now. Lots of features are incomplete.

Preview

landing page

articles feed page

profile page

profile settings page

markdown editor page

about page

Feed dark mode

articles feed page

article desktop

desktop article page

Disclosure

FRONTEND: The core architecture, overall layout, and design system (color schemes, typography) were completely designed and developed by me. I also independently built the majority of the pages, including the Landing Page, Feed, PostView, Profile, About, and Contact pages.

To accelerate development, I used AI tools (Claude and Gemini) to help draft and iterate on specific frontend components, primarily for the Collection and Saved pages.

BACKEND: Everything done by me. I used claude to document some files as they were too large for me to maintain and documentise in my current time frame.

TEST: DB seeding codes & Autocannon, Artillery Test codes written by me, updated with gemini.

About

OpenCanvas: Find and read high-quality scientific articles, research papers, and compelling stories. Explore our library and expand your knowledge today.

www.opencanvas.institute

Topics

react design express node mongodb mern-stack tailwindcss

Resources

Readme

License

GPL-3.0 license
Activity

Stars

5 stars

Watchers

1 watching

Forks

0 forks
Report repository

Releases

No releases published

Packages





Contributors

Languages
